SONIX CX4
close

The most popular groupsets

Recommended groupset Price incl. tax Weight
RockShox Recon NX Eagle 1x12sp Fulcrum Ritchey Comp 47 736 Kč 10998g
RockShox Recon GX Eagle 1x12sp Mavic Ritchey Comp 52 767 Kč 10593g
RockShox Recon Sh SLX 1x11sp Mavic Ritchey Comp 53 580 Kč 10628g
RockShox Reba Sh XT 1x11sp Mavic Ritchey WCS 66 521 Kč 10198g
RockShox Reba X01 Eagle 1x12sp Mavic Ritchey WCS 74 307 Kč 10058g
RockShox Reba Sh XTR 1x11sp Fulcrum Ritchey WCS 89 646 Kč 9744g
RockShox Reba Sh XT Di2 1x11sp Fulcrum Ritchey WCS 96 799 Kč 10194g
RockShox SID XX1 Eagle 1x12sp Mavic Ritchey WCS 109 993 Kč 9525g
RockShox Reba X01 Eagle AXS Mavic Ritchey WCS 111 687 Kč 10025g
RockShox SID XX1 Eagle AXS Mavic Ritchey WCS 124 767 Kč 9876g
RockShox SID Sh XTR Di2 1x11sp Fulcrum Ritchey WCS 138 625 Kč 9496g

Konfigurujete pouze rám. Pro Vaši lepší představu Vám zobrazujeme celé kolo.

OK

SONIX CX4

29er 1x11/12sp

BIKE PRICE
from 47 736 Kč
with groupset
RockShox Recon NX Eagle 1x12sp Fulcrum Ritchey Comp

Color

Frame colour Logo colour Frame colour Big stripe colour Small wave colour Logo colour Frame colour Colour - front part Colour - stripes Logo colour front Logo colour rear Frame color (matt) Stickers (glossy) Fork color Colour of saddle Base Frame Loading
  • Design

  • Mono Mono

    Frame colour

    • Arctic White
    • Attractive Green
    • Eclipse Black
    • Ultramarine Blue
    • Fire Red
    • Light Blue
    • Classic Yellow
    • Orange
    • Light Pink
    • 1504 Light Silver
    • 1505 Classic Silver
    • 1506 Titan Grey
    • 1507 Anthrazit Grey
    • 1510 Gold

    Logo colour

    • CA171 White
    • CA172 Black
    • CA174 Titan Grey
    • 1510 Gold
  • Across Across

    Frame colour

    • Arctic White
    • Attractive Green
    • Eclipse Black
    • Ultramarine Blue
    • Fire Red
    • Light Blue
    • Classic Yellow
    • Orange
    • Light Pink

    Big stripe colour

    • Arctic White
    • Attractive Green
    • Eclipse Black
    • Ultramarine Blue
    • Fire Red
    • Light Blue
    • Classic Yellow
    • Orange
    • Light Pink

    Small wave colour

    • White
    • Green
    • Black
    • Red

    Logo colour

    • CA171 White
    • Green
    • CA172 Black
    • Ultramarine Blue
    • Red
    • Light Blue
    • Classic Yellow
    • Orange
    • Light Pink
  • Trendy Trendy

    Frame colour

    • Arctic White
    • Attractive Green
    • Eclipse Black
    • Ultramarine Blue
    • Fire Red
    • Light Blue
    • Classic Yellow
    • Orange
    • Light Pink

    Colour - front part

    • Arctic White
    • Attractive Green
    • Eclipse Black
    • Ultramarine Blue
    • Fire Red
    • Light Blue
    • Classic Yellow
    • Orange
    • Light Pink

    Colour - stripes

    • White
    • Black

    Logo colour front

    • CA171 White
    • CA172 Black

    Logo colour rear

    • CA171 White
    • CA172 Black
  • Fork color

    • Black
  • Colour of saddle

    • White
    • Black
  • Logo on frame

    Choose your logo

Extra charge paintjob:
Inclusive

Extra charge logo: 0 Kč

  • Change background

    • Dark
    • Light
Share on FB Download

Favouriter designs:

Frame size

Basic Rider parameters

The smallest possible body height is 148cm The greatest possible body height is 210cm
The smallest possible weight is 40 kg The smallest possible weight is 40 kg The greatest possible weight is 150 kg The greatest possible weight is 150 kg

Rider profile

Describe yourself as a rider. This helps us with recommendations on appropriate components and setting a sitting position.

Ambition

Health: You do not cycle for sport, but you love being out in nature and discover new things.

Hobby: Cycling means leisure to you. You do cycle to enjoy nature and keep yourself fit.

Sport: You do cycling for sport. When you are on the bike, you want to train yourself and compete with your friends.

Race: You are training seriously on your bike and sometimes compete at marathons and other races.

Professional: You want to win races at a high level, so being fast is the most important to you.

Experience

You are just starting to discover cycling for yourself.

You are just starting to discover cycling for yourself, but you do other sports on a regular basis.

You started cycling one or two years ago, and last year you did about 2000 km on your bike.

You spend lots of your time one you bike, which adds up to around 5000 km a year.

You have been cycling seriously for a long time and do 10 000 or more km a year.

Velikost rámu je nestandardní, musíme Vám vyrobit rám na míru. Budeme Vás kontaktovat

OK
VR
cm
VR
inch
VP
cm
A1
mm
A2
mm
B2
mm
C1
mm
C2
mm
D
mm
F
mm
G
mm
H
mm
K
mm
L
mm
O
mm
R
mm
S
mm
α
deg
β
deg
44 17,3 167 - 171 586 569 440 445 450 298 115 667 1108 46 88,5 794 408 621 69,5 74,0
46 18,1 172 - 176 595 576 460 445 450 298 115 676 1117 46 88,5 804 417 621 69,5 74,0
48 18,9 177 - 181 608 586 480 445 450 298 115 683 1124 46 88,5 814 424 621 69,5 73,5
50 19,7 182 - 186 620 597 500 445 450 298 115 689 1131 46 85,0 824 435 623 70,0 73,5
52 20,5 187 - 191 633 610 520 445 450 298 125 703 1144 46 85,0 839 446 633 70,0 73,5
54 21,3 192 - 196 645 622 540 445 450 298 135 715 1157 46 85,0 853 455 642 70,0 73,5
56 22,0 197 - 201 658 634 560 445 450 298 145 723 1164 46 85,0 867 459 651 70,0 73,0



Dimension

Summary

Thank you for your interest in a customised bicycle built by us.

You can now either SAVE AS PDF which you can print out for yourself or you can. START AGAIN if you feel that the configuration needs to be changed. EMAIL US to allow us to look over your configuration and we can advise by calling you direct. ADD TO BASKET will confirm your order with us and we will contact you by telephone to confirm. Payment is made at the time of order. Thank you

Price for complete bike 0 Kč

Weight 1480g

Save as PDF Start again Email Us Add to basket You must have selected the size of the frame and components to continue.

X

Your demand

Complete the following items so we can contact you back.




SONIX CX4 29er 1x11/12sp

New - frameset – The Sonix 29", which in technical terms reflects the single cranksets, such as SRAM Eagle - 1x12sp. All cables are completely internally, and it doesn't have a single cable stop weld-on. The technically very clean design consists of the internal running of the Bowden cable to the derailleur and the internal running of the rear brake hose. The cable housing emerges close to the rear hanger.

This frame is a purely racing concept focusing on minimum weight. Double butted 7020T6 alloy tubes are used for the frame construction. Thanks to the large diameter they effectively resist dynamic load during races, and their rigidity gives the competitor immediate acceleration and correct handling of the bike. The effect given by the combination of 29" wheels and a 1x12 gear ratio is improved yet further by the rear axle in a version for fixed axle of 12mm. Thanks to the short & tight rear triangle over a fixed axle, maximum lateral rigidity is ensured even during the most dynamic stages of the race.

The entire concept of the frame in linking with the latest trends in components for cross-country races has set the precedent of this frame to be a racing top model of the brand DURATEC. During the construction of complete bikes we got to a bike weight of around 9.4 kg.

Frame geometry
download the table: male geometry | female geometry

Custom frame construction: if you have an atypical build, we will happily prepare custom frame geometry on the basis of values measured by the FOG system or we will perform the adjustment according to your requirements.

Standard fittings
fitting bottle cages to the seat and down tube, replaceable hanger for derailleur, seat clamp diameter is 31.8 mm, disc brake is post mount,  1 1/8" - 1 1/2” FSA ORBIT IS2 headset

Extra version
rear dropouts BOOST 148/12 mm, max tyre width 2.4"

Connecting dimensions
geometry of frame adapted to suspension forks 29" with travel of 80-100mm, wheel diameter 29", brake disc diameter 140mm (or with adapter for 160mm), fork steerer 1 1/8" - 1 1/2", diameter of seat post 27.2 mm, BSA bottom bracket (width 68 mm), rear hangers 142/12 mm, max tyre width 2.25"

Benefits

The cable housing for the derailleur and hydraulic hose of the rear brake emerge from the front of the top tube. They continue inside the frame and go to the rear stays. They come out just above the rear dropouts. The conical head tube is for a bearing 1-1/8"- 1-1/2". The larger diameter of the bearing in the lower part of the head ensures optimal distribution of the flexing moment from the braking force at this fixed point. FSA ORBIT IS2 industrial enclosed bearings are part of each frame.

Internal cable routing Sram XX1 Eagle

The SRAM XX1 Eagle set is a hot item from 2017! The incredible range of the gearing is optimised for cross-country races in particular. In technological terms the XX1 Eagle is a highly advanced set combining technical advance and the use of very light materials! Gearing range 500% Smooth running, precise gear change, greater robustness - that's how the experts see the XX1 Eagle.

SRAM XX1 Eagle cranks with possibility of selecting cranksets in a range of 30-32-34-36-38 teeth. Depicted variant of cranks 36 teeth, 175 mm from SRAM Eagle GOLD. The cassette has the greatest possible range of 10-50 teeth in 12 sprockets.

1x12 speed Mounting of rear brake

Rear disc brake post mount system. Diameter of rear disk 140 mm, a 160 mm diameter disk can be used if an adapter is used. Based on our experience, we recommend the use of a rear disk of diameter 140 mm and front disk of 160 mm diameter for racing. The rear wheel is fixed in the frame using the fixed axle Syntace X-12. Syntace X-12 with rear axle greatly increases the rigidity and strength of fixing of the rear wheel. It is far stronger than conventional fixing using a quick-release mechanism.

Rear dropouts Syntace X12 Bottom bracket Press Fit

In the standard version the frame is prepared in terms of construction for the conventional BSA bottom bracket of width 68 mm. In the photograph there is a detail of the 90 mm Press Fit GXP bottom bracket with SRAM XX1 Eagle cranks. The design of the rear triangle construction is for tyres with a maximum width of 2.25".
